Характеристики
| Connector Type | D Sub |
| Ways, No. of | 5 |
| Connector Shell Size | 5W5 |
| Gender | Socket |
| Termination Method | Solder |
| No. of Mating Cycles | 500 |
| Material | Steel |
| Approval Category | DIN 41652, part 1 |
| Contact Material | Copper Alloy |
| Contact Plating | Gold over Nickel |
| Current Rating | 5A |
| Flammability Rating | UL94V-0 |
| Insulator Material | Steel |
| Plating | Tin |
| Temp, Op. Max | 125°C |
| Temp, Op. Min | 55°C |
| Voltage, Working | 750V |
| DC Current Max | 5A |
| Secondary Insulation Material | Termoplastic resin, glassfibre filled |
| Voltage, Proof | 750V |
09693000055HARTING ElektronikD-Sub Connectors
