10PCV2415
Sensata
Solid State Relays
RELAY, SSR, 15A
Характеристики
| Control Voltage Range | 2V DC to 10V DC |
| Operating Voltage Range | 100Vrms to 240Vrms |
| Load Current | 15A |
| Relay Terminals | Screw |
| SVHC | No SVHC (20-Jun-2011) |
| Blocking Voltage | 600V |
| Control Current @ 5VDC | 4mA |
| Control Voltage DC Max | 10VDC |
| Control Voltage DC Min | 2VDC |
| Control Voltage Type | DC |
| External Depth | 58.4mm |
| External Length / Height | 23mm |
| External Width | 45.7mm |
| I2t | 94s |
| Isolation Voltage | 2.5kV |
| Leakage Current | 10mA |
| Load Current RMS Max | 15A |
| RMS Load Current Min | 150mA |
| RMS Load Voltage Max | 240V |
| RMS Load Voltage Min | 100V |
| Rate of Voltage Change dv / dt | 200V/µs |
| Series | PCV |
| Surge Current | 150A |
| Terminal Type | Screw Clamp |
