3008012
Phoenix Contact
Terminal Blocks
Характеристики
| Positions | 2 |
| Wire Size AWG Max. AWG | 0 |
| Wire Size AWG Min. AWG | 18 |
| Wire Size mm2 Max. mm² | 50 |
| Wire Size mm2 Min. mm² | 0.75 |
| Wire Size mm2 Nominal mm² | 35 |
| Wire Connection Method | Screw |
| Current Rating A | 125 |
| Voltage Rating kV | 1 |
| Number of Levels | 1 |
| Terminal Block Colour | Grey |
| Pitch mm | 15.1 |
| Standards Met | UL Listed |
| Standards Met | ATEX |
| Standards Met | CSA |
| Standards Met | DNV Germanischer Lloyd |
| Standards Met | EAC |
| Standards Met | EAC Ex |
| Standards Met | Germanischer Lloyd |
| Standards Met | IECEE CB |
| Standards Met | IECEx |
| Standards Met | KEMA-KEUR |
| Standards Met | KR |
| Standards Met | NK |
| Standards Met | PRS |
| Combustibility Class | UL 94 V-0 |
