3031270
Phoenix Contact
Terminal Blocks
Характеристики
| Positions | 4 |
| Wire Size AWG Max. AWG | 12 |
| Wire Size AWG Min. AWG | 28 |
| Wire Size mm2 Max. mm² | 4 |
| Wire Size mm2 Min. mm² | 0.08 |
| Wire Size mm2 Nominal mm² | 2.5 |
| Wire Connection Method | Spring Clamp |
| Current Rating A | 22 |
| Voltage Rating V | 500 |
| Number of Levels | 2 |
| Terminal Block Colour | Grey |
| Pitch mm | 5.2 |
| Standards Met | UL Listed |
| Standards Met | ATEX |
| Standards Met | CSA |
| Standards Met | DNV Germanischer Lloyd |
| Standards Met | EAC |
| Standards Met | EAC Ex |
| Standards Met | IECEE CB |
| Standards Met | IECEx |
| Standards Met | KR |
| Standards Met | LR |
| Standards Met | NK |
| Standards Met | VDE |
| Combustibility Class | UL 94 V-0 |
