Характеристики
| Resistance kOhm | 50 |
| Tolerance | ±20 % |
| Power Rating mW | 250 |
| Number of Turns | 1 |
| Number of Gangs | 1 |
| Rotation Angle ° | 270 |
| Track Taper | Linear |
| Orientation | Right Angle |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 125 |
| Shaft Type | Slotted |
| Shaft Diameter mm | 3.18 |
| Shaft Length mm | 12.7 |
| Termination Type | PCB Pins |
| Mounting Type | Panel Mount |
| Series | 3310 |
| Height mm | 9.53 |
PDF3310Y-001-503LBournsVariable Resistors and Potentiometers
