Характеристики
| Pitch Spacing | 2.54mm |
| No. of Contacts | 20Contacts |
| Gender | Receptacle |
| Product Range | Dubbox 89898 Series |
| Contact Termination Type | Solder |
| No. of Rows | 2Rows |
| Contact Plating | Gold Plated Contacts |
| Contact Material | Phosphor Bronze |
| SVHC | No SVHC (15-Jan-2019) |
| Colour | Grey |
| Contact Resistance | 15mohm |
| Contact Termination | Solder |
| Current per Contact Max | 3A |
| Flammability Rating | UL94V-0 |
| Insulation Resistance | 100000Mohm |
| Lead Spacing | 2.54mm |
| Material | High Temperature Thermoplastic |
| No. of Mating Cycles | 200 |
| Operating Temperature Max | 125°C |
| Operating Temperature Min | -65°C |
| Row Pitch | 2.54mm |
| Termination Method | Solder |
| Withstand Voltage | 1000V |
89898-310ALFAmphenol Communications SolutionsCard Edge Connectors
