Характеристики
| Channels | 4 |
| Number of Converters | 4 |
| Architecture | Resistor String |
| Resolution Bit | 12 |
| Differential Nonlinearity (DNL) LSB | 0.2 |
| Interfaces | 3-Wire |
| Interfaces | DSP |
| Interfaces | Microwire |
| Interfaces | SPI |
| Reference Type | External |
| Single Supply Voltage Min. V | 2.5 |
| Single Supply Voltage Max. V | 5.5 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 105 |
| Package Type | MSOP |
| Pins | 10 |
| Mounting Type | SMD |
| MSL | Level-1 |
| Packaging | Tube |
| Length mm | 3 |
| Width mm | 3 |
| Height mm | 0.85 |
| Reflow Temperature Max. °C | 260 |
| Power Supply Type | Single |
AD5324BRMZAnalog DevicesAnalog to Digital Converters (ADCs)
