Характеристики
| Resolution (Bits) | 8bit |
| Sampling Rate | 1.7MSPS |
| Data Interface | Serial |
| Supply Voltage Range | 2.7V to 5.5V |
| ADC / DAC Case Style | SC-70 |
| No. of Pins | 6Pins |
| Input Channel Type | Serial |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 125°C |
| Product Range | - |
| Automotive Qualification Standard | - |
| MSL | MSL 1 - Unlimited |
| SVHC | No SVHC (07-Jul-2017) |
| A/D / D/A Features | Power-on-reset to 0 V with brownout detection, 3 power-down functions, Minimized zero code error |
| Base Number | 5601 |
| IC Case Style | SC-70 |
| IC Generic Number | 5601 |
| Linearity Error | 0.0004% |
| Linearity Error ADC / DAC + | 0.5LSB |
| Linearity Error ADC / DAC - | 0.5LSB |
| Logic Function Number | 5601 |
| No. of Bits | 8bit |
| No. of Channels | 1Channels |
| Operating Temperature Range | -40°C to +125°C |
| Output Type | Voltage |
| Settling Time | 8µs |
| Supply Current | 75µA |
| Supply Voltage Max | 5.5V |
| Supply Voltage Min | 2.7V |
| Termination Type | Surface Mount Device |
AD5601BKSZ-500RL7Analog DevicesDigital to Analog Converters (DACs)
