Характеристики
| Channels | 16 |
| Number of Converters | 1 |
| Architecture | SAR |
| Resolution Bit | 12 |
| Interfaces | SPI |
| Interfaces | QSPI |
| Interfaces | Microwire |
| Sample Rate MSPS | 1 |
| Signal-to-Noise Ratio (SNR) dB | 69.5 |
| Integral Nonlinearity (INL) LSB | 1 |
| Input Type | Single Ended |
| Reference Type | External |
| Power Consumption mW | 12.5 |
| Single Supply Voltage Min. V | 2.7 |
| Single Supply Voltage Max. V | 5.3 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 85 |
| Package Type | TSSOP |
| Pins | 28 |
| Mounting Type | SMD |
| Packaging | Tube |
| Length mm | 9.7 |
| Width mm | 4.4 |
| Height mm | 1.1 |
| Power Supply Type | Single |
AD7490BRUZAnalog DevicesAnalog to Digital Converters (ADCs)
