AD8544ARUZ
Amplifiers - Op Amps, Buffer, Instrumentation
Slew Rate V / Voltage Gain V / Input Voltage Noise Density nV
Характеристики
| Amplifier Type | CMOS |
| Gain Bandwidth MHz | 1 |
| ms | 750 |
| Input Offset Voltage mV | 1 |
| Input Bias Current pA | 4 |
| Amplifiers | 4 |
| Common Mode Rejection Ratio (CMRR) dB | 40 |
| Power Supply Rejection Ratio (PSRR) dB | 65 |
| mV | 500 |
| √Hz | 40 |
| Output Current per Channel mA | 15 |
| Supply Current uA | 45 |
| Single Supply Voltage Min. V | 2.7 |
| Single Supply Voltage Max. V | 5.5 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 125 |
| Package Type | TSSOP |
| Pins | 14 |
| Mounting Type | SMD |
| MSL | Level-1 |
| Packaging | Tube |
| Length mm | 5 |
| Width mm | 4.4 |
| Height mm | 1 |
| Power Supply Type | Single |
| Reflow Temperature Max. °C | 260 |
AD8544ARUZAnalog DevicesAmplifiers - Op Amps, Buffer, Instrumentation
