Характеристики
| Comparator Type | Ultrafast |
| Output Type | CMOS |
| Output Type | TTL |
| Channels | 1 |
| Input Offset Voltage Max. mV | 7 |
| Common Mode Rejection Ratio (CMRR) dB | 55 |
| Power Supply Rejection Ratio (PSRR) dB | 55 |
| Supply Current mA | 5.7 |
| Single Supply Voltage Min. V | 3 |
| Single Supply Voltage Max. V | 5 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 85 |
| Package Type | SOIC |
| Pins | 8 |
| Mounting Type | SMD |
| MSL | Level-1 |
| Packaging | Tube |
| Length mm | 5 |
| Width mm | 4 |
| Height mm | 1.5 |
| Reflow Temperature Max. °C | 260 |
| Power Supply Type | Single |
AD8611ARZAnalog DevicesComparators
