AD8639ARZ
Amplifiers - Op Amps, Buffer, Instrumentation
Slew Rate V / Input Voltage Noise Density nV
Характеристики
| Amplifier Type | Wideband |
| Gain Bandwidth MHz | 1.4 |
| us | 2.5 |
| Input Offset Voltage uV | 9 |
| Input Bias Current pA | 40 |
| Amplifiers | 2 |
| Common Mode Rejection Ratio (CMRR) dB | 118 |
| Power Supply Rejection Ratio (PSRR) dB | 127 |
| Voltage Gain dB | 136 |
| √Hz | 60 |
| Supply Current mA | 1.3 |
| Single Supply Voltage Min. V | 5 |
| Single Supply Voltage Max. V | 16 |
| Dual Supply Voltage Min. V | 2.5 |
| Dual Supply Voltage Max. V | 8 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 125 |
| Package Type | NSOIC |
| Pins | 8 |
| Mounting Type | SMD |
| Packaging | Tube |
| Length mm | 5 |
| Width mm | 4 |
| Height mm | 1.5 |
| Power Supply Type | Dual |
| Power Supply Type | Single |
AD8639ARZAnalog DevicesAmplifiers - Op Amps, Buffer, Instrumentation
