ADA4898-1YRDZ
Amplifiers - Op Amps, Buffer, Instrumentation
Slew Rate V / Input Voltage Noise Density nV
Характеристики
| Amplifier Type | High Speed |
| Gain Bandwidth MHz | 50 |
| us | 50 |
| Input Offset Voltage uV | 160 |
| Input Bias Current nA | 500 |
| Amplifiers | 1 |
| Common Mode Rejection Ratio (CMRR) dB | 102 |
| Power Supply Rejection Ratio (PSRR) dB | 95 |
| Voltage Gain dB | 94 |
| √Hz | 0.9 |
| Output Current per Channel mA | 8 |
| Supply Current mA | 8 |
| Dual Supply Voltage Min. V | 4.5 |
| Dual Supply Voltage Max. V | 16.5 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 105 |
| Package Type | NSOIC |
| Pins | 8 |
| Mounting Type | SMD |
| Packaging | Tube |
| Length mm | 4.9 |
| Width mm | 3.9 |
| Height mm | 1.7 |
| Power Supply Type | Dual |
ADA4898-1YRDZAnalog DevicesAmplifiers - Op Amps, Buffer, Instrumentation
