CWD2450-10
Sensata
Solid State Relays
RELAY, SOLID STATE, 50A, 240VAC
Характеристики
| Series | CW24 |
| Control Voltage Type | DC |
| Max Load Current RMS | 50A |
| Min Load Current RMS | 0.15A |
| Current, Surge | 850A |
| Voltage, Load RMS Max | 280V |
| Voltage, Load RMS Min | 24V |
| Terminal Type | Screw Type |
| Approval Bodies | CSA, VDE, CE |
| Approval Category | UL Recognised |
| Control Current Typ | 10mA |
| External Depth | 58.4mm |
| External Length / Height | 33mm |
| I2t | 3000s |
| Leakage Current | 1mA |
| Max Load Current | 50A |
| Min Load Current | 0.15A |
| Output Type | SCR |
| Resistance, Insulation | 1000Mohm |
| Temp, Op. Max | 80°C |
| Temp, Op. Min | -40°C |
| Voltage, Blocking | 600V |
| Voltage, Control DC Max | 32V |
| Voltage, Control DC Min | 3V |
| Voltage, Drop @ Rated Current | 1.3V |
| Width, External | 45.7mm |
| dv/dt | 500V/µs |
