CX480D5
Sensata
Solid State Relays
SSR, 5A, 480VAC
Характеристики
| Control Voltage Type | DC |
| Input Voltage | 4V DC to 15 VDC |
| Contact Configuration | SPST-NO |
| Load Current | 5A |
| Load Voltage Range | 48Vrms to 660Vrms |
| Switching Mode | Zero Cross |
| Relay Terminals | Through Hole |
| SVHC | No SVHC (20-Jun-2011) |
| Blocking Voltage | 1200V |
| Contact Configuration | SPST-NO |
| Control Current @ 5VDC | 15mA |
| Control Voltage DC Max | 15V |
| Control Voltage DC Min | 4V |
| Current Load AC Max | 5A |
| External Depth | 7.6mm |
| External Length / Height | 25.4mm |
| External Width | 43mm |
| I2t | 260s |
| Input Impedance | 240ohm |
| Isolation Voltage | 4kV |
| Leakage Current | 0.1mA |
| Load Current Min | 0.06A |
| Load Current RMS Max | 5A |
| Output Type | SCR |
| RMS Load Current Min | 0.06A |
| RMS Load Voltage Max | 660V |
| RMS Load Voltage Min | 48V |
| Rate of Voltage Change dv / dt | 500V/µs |
| Series | CX |
| Surge Current | 250A |
| Terminal Type | Through Hole |
| Voltage Drop @ Rated Current | 1.4V |
