CXE380D5
Sensata
Solid State Relays
SSR, 5A, 380VAC
Характеристики
| Contact Configuration | SPST-NO |
| Load Current | 5A |
| Switching Mode | Zero Crossing |
| Relay Terminals | Through Hole |
| SVHC | No SVHC (18-Jun-2012) |
| Approval Bodies | CSA / VDE |
| Approval Category | UL Recognised |
| Blocking Voltage | 1200V |
| Contact Configuration | SPST-NO |
| Contact Type | Zero-cross |
| Control Current Typ | 15mA |
| Control Voltage DC Max | 32V |
| Control Voltage DC Min | 15V |
| Control Voltage Type | DC |
| Current Load AC Max | 5A |
| Dielectric Strength VAC | 4000V |
| External Depth | 7.6mm |
| External Length / Height | 25.4mm |
| External Width | 43.1mm |
| I2t | 260s |
| Input Impedance | 1500ohm |
| Input Voltage | 15V DC to 32V DC |
| Leakage Current | 0.1mA |
| Load Current Min | 0.06A |
| Load Current RMS Max | 5A |
| Load Voltage Range | 48Vrms to 530Vrms |
| No. of Pins | 4 |
| Operating Temperature Max | 80°C |
| Operating Temperature Min | -30°C |
| Output Type | SCR |
| Pin Length | 7.6mm |
| RMS Load Current Min | 0.06A |
| RMS Load Voltage Max | 530V |
| RMS Load Voltage Min | 48V |
| Rate of Voltage Change dv / dt | 500V/µs |
| Series | CX |
| Surge Current | 250A |
| Termination Type | SIP |
