FS10-12
XP Power
Board Mount Modules
Характеристики
| Outputs | 1 |
| Output Voltage 1 kV | 1 |
| Output Current 1 mA | 10 |
| Adjustable Output Voltage Min. V | 58 |
| Adjustable Output Voltage Max. kV | 1 |
| Output Type | Adjustable |
| Rated Power W | 10 |
| Input Voltage Min. mV | 700 |
| Input Voltage Max. V | 12 |
| Mounting Type | Through Hole |
| Termination Type | PCB Pins |
| Ripple & Noise (%) % | 2.5 |
| Protection Type | Over Voltage Protection |
| Protection Type | Short Circuit Protection |
| Protection Type | Over Temperature Protection |
| Insulation Voltage kV | 2.5 |
| MTBF h | 840000 |
| Length mm | 57.2 |
| Width mm | 28.5 |
| Height mm | 12.7 |
| Warranty | 3 Years |
FS10-12XP PowerBoard Mount Modules
