Характеристики
| Inductance | 2.2µH |
| Inductance Tolerance | ± 20% |
| DC Resistance Max | 2530µohm |
| DC Current Rating | 35A |
| Inductor Case Style | 6767GZ |
| No. of Pins | 2 |
| Core Material | Iron Powder |
| Core Material | Powdered Iron |
| DC Current Max | 35A |
| External Depth | 17.15mm |
| External Length / Height | 7mm |
| External Width | 17.15mm |
| Inductor Type | High Current |
| Operating Temperature Max | 125°C |
| Operating Temperature Min | -55°C |
| Package / Case | SMD |
| Resistance | 2.4mohm |
| Saturation Current Ic | 62A |
IHLP6767GZER2R2M01VishayFixed Inductors
