Характеристики
| Sensor Type | Proximity-Magnetic Switch |
| Contact Configuration | 1CO |
| Switching Capacity W | 10 |
| Switching Voltage - AC V | 175 |
| Switching Voltage - DC V | 175 |
| Switching Current Max. - AC mA | 500 |
| Switching Current Max. - DC mA | 500 |
| Breakdown Voltage VDC | 200 |
| Shock Resistance g | 50 |
| Termination Type | Cable, 500 mm |
| Release Time ms | 1.5 |
| Contact Resistance mOhm | 150 |
| Mounting Type | Screw |
| Series | MK04 |
| Operating Temperature Min. °C | -5 |
| Operating Temperature Max. °C | 70 |
| Length mm | 23 |
| Width mm | 14 |
| Height mm | 5.9 |
MK04-1C90C-500WStandex-Meder ElectronicsProximity Sensors
