OP482GSZ
Amplifiers - Op Amps, Buffer, Instrumentation
Slew Rate V / Power Supply Rejection Ratio (PSRR) uV / Voltage Gain mV / Input Voltage Noise Density nV
Характеристики
| Amplifier Type | JFET Operational |
| Gain Bandwidth MHz | 4 |
| us | 9 |
| Input Offset Voltage uV | 200 |
| Input Bias Current pA | 3 |
| Amplifiers | 4 |
| Common Mode Rejection Ratio (CMRR) dB | 70 |
| V | 25 |
| V | 20 |
| √Hz | 36 |
| Supply Current uA | 840 |
| Dual Supply Voltage Min. V | 4.5 |
| Dual Supply Voltage Max. V | 18 |
| Operating Temperature Min. °C | -40 |
| Operating Temperature Max. °C | 85 |
| Package Type | NSOIC |
| Pins | 14 |
| Mounting Type | SMD |
| MSL | Level-1 |
| Packaging | Tube |
| Length mm | 8.75 |
| Width mm | 4 |
| Height mm | 1.5 |
| Power Supply Type | Dual |
| Reflow Temperature Max. °C | 260 |
OP482GSZAnalog DevicesAmplifiers - Op Amps, Buffer, Instrumentation
