Характеристики
| Outputs | 1 |
| Output Voltage 1 V | 5 |
| Output Current 1 A | 1.6 |
| Output Type | Fixed |
| Rated Power W | 8 |
| Input Voltage Min. V | 18 |
| Input Voltage Max. V | 36 |
| Mounting Type | Through Hole |
| Termination Type | PCB Pins |
| Package Type | DIP |
| Efficiency % | 78 |
| Ripple & Noise (V) mV | 50 |
| Protection Type | Short Circuit Protection |
| Protection Type | Overload Protection |
| Insulation Voltage kV | 1.5 |
| MTBF h | 900000 |
| Length mm | 32 |
| Width mm | 20 |
| Height mm | 12 |
| Warranty | 2 Years |
SCW08B-05Mean WellBoard Mount Modules
