Характеристики
| Logic Family / Base Number | TTL00 |
| Logic Type | NAND |
| Output Current | 16mA |
| No. of Inputs | 8 |
| Supply Voltage Min | 4.75V |
| Supply Voltage Max | 5.25V |
| Logic Case Style | DIP |
| No. of Pins | 14Pins |
| Logic IC Family | TTL |
| Logic IC Base Number | 7400 |
| Operating Temperature Min | 0°C |
| Operating Temperature Max | 70°C |
| Product Range | - |
| Automotive Qualification Standard | - |
| RoHS Phthalates Compliant | Yes |
| MSL | - |
| SVHC | No SVHC (27-Jun-2018) |
| Base Number | 7400 |
| Logic Function Number | 7400 |
| Logic IC Function | Quadruple 2-Input NAND Gate |
SN7400NTexas InstrumentsLogic Gates
