Характеристики
| Voltage Reference Type | Shunt - Adjustable |
| Product Range | - |
| Reference Voltage | 2.495V to 36V |
| Initial Accuracy | 2% |
| Temperature Coefficient | - |
| Voltage Reference Case Style | DIP |
| No. of Pins | 8Pins |
| Operating Temperature Min | 0°C |
| Operating Temperature Max | 70°C |
| Automotive Qualification Standard | - |
| RoHS Phthalates Compliant | Yes |
| MSL | - |
| SVHC | No SVHC (27-Jun-2018) |
| Accuracy % | 2% |
| Base Number | 431 |
| Cathode Current Ik Max | 100mA |
| IC Generic Number | 431 |
| IC Temperature Range | Commercial |
| Input Voltage | 2.495V to 36V |
| Input Voltage Max | 36V |
| Input Voltage Min | 2.495V |
| Operating Temperature Range | 0°C to +70°C |
| Operating Voltage Tolerance + | 2% |
| Output Current Max | 100mA |
| Output Voltage Max | 36V |
| Output Voltage Min | 2.5V |
| Reference Volt Tolerance ±% | 2% |
| Reference Voltage Tolerance | 50mV |
| Reference Volts | 2.495V |
| Temperature Coeff Over Temp Range | 6mV |
| Termination Type | Through Hole |
| Topology | Shunt, Adjustable |
| Voltage Regulator Type | Positive Adjustable |
TL431CPTexas InstrumentsVoltage References
