Характеристики
| Voltage Reference Type | Shunt - Adjustable |
| Product Range | TL431 Series |
| Reference Voltage | 2.495V to 36V |
| Initial Accuracy | 2% |
| Temperature Coefficient | - |
| Voltage Reference Case Style | SOT-89 |
| No. of Pins | 3Pins |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 125°C |
| Automotive Qualification Standard | - |
| MSL | MSL 2 - 1 year |
| SVHC | No SVHC (15-Jan-2019) |
| Base Number | 431 |
| Input Voltage | 2.495V to 36V |
| Input Voltage Max | 36V |
| Input Voltage Min | 2.495V |
| Operating Temperature Range | -40°C to +125°C |
| Reference Volt Tolerance ±% | 2.2% |
| Reference Voltage Tolerance | 55mV |
| Reference Volts | 2.495V |
| Topology | Shunt, Programmable |
TL431QPKTexas InstrumentsVoltage References
