Характеристики
| Series | 2381593 |
| Peak Energy (10/1000uS) | 17J |
| Voltage Rating VDC | 170V |
| Voltage Rating VAC | 130V |
| Operating Temperature Range | -40°C to +125°C |
| Approval Category | UL, VDE |
| Clamping Voltage | 340V |
| Clamping Voltage @ 8/20µs Max | 340V |
| External Depth | 6mm |
| External Length / Height | 13mm |
| External Width | 9mm |
| Lead Diameter | 0.6mm |
| Lead Length | 20mm |
| Package / Case | Radial |
| Power Rating | 250mW |
| Suppressor Type | Metal Oxide Varistor (MOV) |
| Surge Current | 1200A |
| Temperature Coefficient | ± 0.05%/K |
| Varistor Voltage @ 1mA | 185V |
| Varistor Voltage @ 1mA Max | 225V |
| Voltage Rating | 170VDC |
VDRS07H130BSEVishayResistors
