Характеристики
| Direction Type | Bi-Directional |
| Reverse Stand-off Voltage Max. V | 5 |
| Clamping Voltage V | 7 |
| Peak Pulse Current A | 4 |
| Breakdown Voltage Min. V | 6 |
| Capacitance pF | 60 |
| Operating Temperature Max. °C | 125 |
| Operating Temperature Min. °C | -40 |
| Reverse Leakage Current Max. uA | 1 |
| Voltage ESD Air Gap Min. kV | -30 |
| Voltage ESD Air Gap Max. kV | 30 |
| Voltage ESD Contact Min. kV | -30 |
| Voltage ESD Contact Max. kV | 30 |
| Pins | 17 |
| Package Type | LLP3313-17L |
| Mounting Type | SMD |
| MSL | Level-1 |
| Packaging | Tape & Reel |
| Reflow Temperature Max. °C | 260 |
VEMI85AA-HGK-GS08VishayEMI / RFI Filters
